F-300
Pitot Tube Acrylic Flow Meter
An aquatics industry standard for over six decades, Blue-White’s F-300 Flow Meter is accurate and has reduced space requirements for installation. The aerodynamic pitot tube is designed for smooth fluid flow through the meter. There are four capture points resulting in no float bounce.
New features include:
- PVDF cap that won’t fade or crack
- PVDF float that won’t stick, is chemical resistant, and easy-to read-color
- Improved accuracy
Recommended Accessories:
F-300S, F-300SL Flow Switch and Sensor
Technical Overview:
GPM
2 - 1900
LPM
8 - 7200
PSI
75
Bar
5.2
Fahrenheit (°F)
190
Celsius (°C)
88
Body Material
Acrylic
Pipe Sizes
1”, 1¼”, 1½”, 2”, 2½”, 3”, 4”, 6”, 8”
Literature
F-300 Literature
Instruction Manuals
F-300 Instruction Manual – 80000-557Technical Data Sheets
F-300 | D-300 | U-300 Technical Data Sheet – 85000-071Quickstart Guides
F-300 Quickstart Guide – 80000-700Brochures
Blue-White Pool Flysheet - 80000-589
Flow Rate Calculator
Pool Flow Rate Calculator
Features
Model Variations:
- F-300 = Horizontal flow
- D-300 = Vertical downflow
- U-300 = Vertical upflow
- NSF 50 LISTED 1”, 1.25”, 1.5”, 2” (L2), 2.5”, 3”, 4”, 6”, and 8″ (L3) – Horizontal flow only
- Well suited for closed pipe installations
- Easy to read dual scale (SCH 40 / SCH 80), screen printed on both sides of the meter body
- Acceptable for outdoor installations (direct sunlight okay)
- Pitot Tube (impact tube) design makes it easy to install on existing pipe
- One-piece, machined acrylic meter body
- Included SS clamps and gasket seal
- For use on PVC (refer to literature)
What’s Included:
- Flowmeter x1
- Rubber Gasket x1
- Clamp x2
- Instruction Manual
Specifications
Horizontal Installation:
- 1″, 1.25″, 1.5″, 2″, 2.5″, 3″, 4″, 6″, 8″
Vertical Installation:
- 1½″, 2″
Max. Working Pressure:
- 75 PSI (5.17 bar) @ 70˚F (21˚C)
Max. Fluid Temperature:
- 190˚F / 88˚C @ 0 PSI
Full Scale Accuracy:
- +/- 5% (L2 Pipe sizes: 1”, 1.25”, 1.5” and 2”)
- +/- 10% (L3 Pipe sizes: 2.5”, 3”, 4”, 6”, and 8”)
Meter Body Material:
- Acrylic
Gasket Material:
- Neoprene
Float Material:
- PVDF
Connection Type:
- Saddle
Pipe Capability:
- PVC Schedule 40 and Schedule 80
Approx. Shipping Weight:
- 1” to 4” Pipe: 1 lb. (.454kg)
- 6” and 8” Pipe: 2 lb. (.907 kg)
Meter Ranges
Horizontal Pipe Installation
Models for U.S. IPS SCH 40 & 80 Pipe (ASTM 1785)
| MODEL NO. | PIPE SIZE | PIPE MATERIAL | SCH 40 (GPM) | SCH 80 (GPM) |
|---|---|---|---|---|
| F-30100P | 1” IPS | PVC | 5 – 35 GPM | 4 – 26 GPM |
| F-30125P | 1 ¼” IPS | PVC | 9 – 50 GPM | 8 – 40 GPM |
| F-30150P | 1½” IPS | PVC | 10 – 70 GPM | 10 – 60 GPM |
| F-30200P | 2” IPS | PVC | 20 – 120 GPM | 18 – 100 GPM |
| F-30250P | 2½” IPS | PVC | 29 – 150 GPM | 25 – 130 GPM |
| F-30300P | 3” IPS | PVC | 45 – 240 GPM | 40 – 215 GPM |
| F-30400P | 4” IPS | PVC | 75 – 420 GPM | 70 – 375 GPM |
| F-30600P | 6” IPS | PVC | 170 – 1100 GPM | 160 – 1000 GPM |
| F-30800P | 8” IPS | PVC | 300 – 2200 GPM | 275 – 1950 GPM |
Horizontal Pipe Installation (Metric)
Models for METRIC Pipe (DIN 8062)
| MODEL NO. | PIPE SIZE | PN10 (LPM) | PN16 (LPM) |
|---|---|---|---|
| F-30032M | 32mm | 30 – 150 LPM | 30 – 130 LPM |
| F-30040M | 40mm | 70 – 310 LPM | 60 – 270 LPM |
| F-30050M | 50mm | 50 – 350 LPM | 50 – 300 LPM |
| F-30063M | 63mm | 100 – 475 LPM | 75 – 400 LPM |
| F-30075M | 75mm | 150 – 700 LPM | 150 – 600 LPM |
| F-30090M | 90mm | 200 – 850 LPM | 200 – 800 LPM |
| F-30110M | 110mm | 600 – 1800 LPM | 550 – 1600 LPM |
Verticle Pipe Installation
Models for U.S. IPS SCH 40 & 80 Pipe (ASTM 1785)
| MODEL NO. | PIPE SIZE | SCH 40 (GPM) | SCH 80 (GPM) |
|---|---|---|---|
| D-30150P | 1½” IPS | 10 – 60 GPM | 10 – 50 GPM |
| D-30200P | 2” IPS | 20 – 110 GPM | 20 – 100 GPM |
| U-30150P | 1½” IPS | 10 – 60 GPM | 10 – 50 GPM |
| U-30200P | 2” IPS | 20 – 110 GPM | 20 – 100 GPM |
Verticle Pipe Installation (Metric)
Models for METRIC Pipe (DIN 8062)
| MODEL NO. | PIPE SIZE | PN10 (LPM) | PN16 (LPM) |
|---|---|---|---|
| U-30050M | 50mm | 100 – 450 LPM | 100 – 400 LPM |
| U-30063M | 63mm | 175 – 675 LPM | 150 – 600 LPM |
| D-30050M | 50mm | 100 – 450 LPM | 100 – 400 LPM |
| D-30063M | 63mm | 175 – 675 LPM | 150 – 600 LPM |
