A-100N
FLEXFLO® Peristaltic Metering Pump
Peristaltic pump design does not have valves that can clog requiring maintenance, is self-priming, and cannot vapor lock or lose prime.
Technical Overview:
GPD
2.4 - 124.08
LPH
.4 - 20
PSI
100
Bar
6.9
Enclosure Rating
NEMA 3R (IP23)
Standards
NSF/ANSI 61, CE, cETLus, RoHS
Control Methods
Manual, Remote Analog/Digital
Power Supply
100 to 240VAC-50/60Hz
Literature
A-100N Literature
Features
Overview
- Patented TFD (Tube Failure Detection) system protects against chemical spills from a worn out tube and activates an alarm output relay
- Self-Priming against maximum line pressure
- Cannot Vapor Lock or Lose Prime
- Tube material options: Norprene®, Norprene® Chemical, and Tygothane®
What’s Included:
- A-100N Peristaltic Metering Pump
- Two tube assemblies
- Discharge injection fitting with check valve
- Suction tube – clear PVC – 5′ length (3/8″ OD, 1/4″ ID)
- Suction strainer
- Suction ceramic weight
- Discharge tube – opaque polyethylene – 5′ length (3/8″ OD, 1/4″ ID)
- Display shield
- Tube nuts (x2)
- Mounting hardware
Output
| Tube Model | Max Pressure | 14 RPM Models | 30 RPM Models | 45 RPM Models | 60 RPM Models* | ||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| PSI (bar) | GPD | GPH | Oz/Min | ML/Min | LPH | GPD | GPH | Oz/Min | ML/Min | LPH | GPD | GPH | Oz/Min | ML/Min | LPH | GPD | GPH | Oz/Min | ML/Min | LPH | |
| 1 | 65(4.5) | 5.7 | 0.24 | 0.51 | 15 | 0.90 | 13.3 | 0.55 | 1.18 | 35 | 2.1 | 20.5 | 0.86 | 1.83 | 54 | 3.24 | 25.5 | 1.06 | 2.26 | 67 | 4.02 |
| 2 | 65(4.5) | 12.2 | 0.51 | 1.08 | 32 | 1.92 | 28.5 | 1.19 | 2.54 | 75 | 4.5 | 43.6 | 1.82 | 3.89 | 115 | 6.90 | 53.3 | 2.22 | 4.73 | 140 | 8.40 |
| 3 | 50(3.5) | 27.8 | 1.16 | 2.47 | 73 | 4.37 | 65.8 | 2.74 | 5.85 | 173 | 10.38 | 99.2 | 4.14 | 8.82 | 261 | 15.66 | 124 | 5.17 | 11.01 | 326 | 19.56 |
| 4 | 100(6.9)* | 2.3 | 0.10 | 0.20 | 6.0 | 0.36 | 4.9 | 0.21 | 0.44 | 13 | 0.78 | 8.0 | 0.33 | 0.71 | 21 | 1.26 | 9.5 | 0.40 | 0.85 | 25 | 1.50 |
| 6 | 100(6.9)* | 6.9 | 0.30 | 0.60 | 18.4 | 1.10 | 16.0 | 0.67 | 1.42 | 42.1 | 2.5 | 24.0 | 1.0 | 2.13 | 63.1 | 3.8 | 30.1 | 1.25 | 2.67 | 79.2 | 4.7 |
| 7 | 50(3.5) | 21.7 | 0.90 | 1.92 | 57.0 | 3.40 | 52.5 | 2.19 | 4.66 | 138 | 8.3 | 76.1 | 3.17 | 6.76 | 200 | 12.0 | 95.1 | 3.96 | 8.45 | 250 | 15.0 |
| 8 | 50(3.5) | 15.2 | 0.63 | 1.35 | 40.0 | 2.40 | 31.9 | 1.31 | 2.80 | 84 | 5.04 | 53.2 | 2.22 | 4.73 | 140 | 8.4 | 68.4 | 2.85 | 6.10 | 180 | 10.8 |
Specifications
Nothing to display here
Variable Speed Pumps
Max. working pressure:
- 100 psig (6.9 bar)
Max. fluid temperature:
- 130 F (54 C)
Max. ambient temperature:
- 14 to 110 F/ -10 to 43 C
Duty cycle:
- Continuous
Maximum viscosity:
- 5,000 Centipoise
Maximum suction lift:
- 30 ft. Water 0 psig
Maximum Solids:
- 50% by volume
Enclosure:
- NEMA 3R, (IP23)
Output adjustment range:
- 14 & 30 RPM with -1T, -2T, -4T tubes: 5-100% (20:1 turndown)
- All other models: 10-100% (10:1 turndown)
Voltage (amp draw):
- 115VAC/60Hz, 1ph (.350 amp max)
- 220VAC/50Hz, 1ph (.175 amp max)
Power Cord Plug Type:
- 115V60Hz = NEMA 5/15 (USA)
- 220V50Hz = CEE 7/VII (EUROPE)
Approximate shipping wt:
- 12 lb. (5.4 kg)
Max. working pressure:
- 100 psig (6.9 bar)
Max. fluid temperature:
- 130 F (54 C)
Max. ambient temperature:
- 14 to 110 F/ -10 to 43 C
Output adjustment range:
- 10-100% in 1% increments
Duty cycle:
- Continuous
Maximum viscosity:
- 5,000 Centipoise
Maximum suction lift:
- 30 ft. Water 0 psig
Maximum Solids:
- 50% by volume
Enclosure:
- NEMA 3R, (IP23)
Voltage (amp draw):
- 115VAC/60Hz, 1ph (.513 amp max)
- 220VAC/50Hz, 1ph (.660 amp max)
Power Cord Plug Type:
- 115V60Hz = NEMA 5/15 (USA)
- 220V50Hz = CEE 7/VII (EUROPE)
Approximate shipping wt:
- 12 lb. (5.4 kg)
Max. working pressure:
- 65 psig (4.5 bar)
Max. fluid temperature:
- 130 F (54 C)
Max. ambient temperature:
- 14 to 110 F/ -10 to 43 C
Output adjustment range:
- 14 & 30 RPM with -1T, -2T tubes: 5-100% (20:1 turndown)
- All other models: 10-100% (10:1 turndown)
Duty cycle:
- Continuous
Maximum viscosity:
- 5,000 Centipoise
Maximum suction lift:
- 30 ft. Water 0 psig
Maximum Solids:
- 50% by volume
Enclosure:
- NEMA 3R, (IP23)
Voltage (amp draw):
- 115VAC/60Hz, 1ph (.350 amp max)
- 220VAC/50Hz, 1ph (.175 amp max)
Power Cord Plug Type:
- 115V60Hz = NEMA 5/15 (USA)
- 220V50Hz = CEE 7/VII (EUROPE)
Approximate shipping wt:
- 12 lb. (5.4 kg)
Max. working pressure:
- 65 psig (4.5 bar)
Max. fluid temperature:
- 130 F (54 C)
Max. ambient temperature:
- 14 to 110 F/ -10 to 43 C
Output adjustment range:
- 10-100% in 1% increments
Duty cycle:
- Continuous
Maximum viscosity:
- 5,000 Centipoise
Maximum suction lift:
- 30 ft. Water 0 psig
Maximum Solids:
- 50% by volume
Enclosure:
- NEMA 3R, (IP23)
Voltage (amp draw):
- 115VAC/60Hz, 1ph (.513 amp max)
- 220VAC/50Hz, 1ph (.660 amp max)
Power Cord Plug Type:
- 115V60Hz = NEMA 5/15 (USA)
- 220V50Hz = CEE 7/VII (EUROPE)
Approximate shipping wt:
- 12 lb. (5.4 kg)
