Buy Blue-White parts for your C-600 Chem-Feed injector pump.

C-600 Replacement Part List

Online purchasing is for Blue-White parts only. Whole goods are sold exclusively through authorized distributors and dealers.
There is a $20 (US) order minimum. US orders only.

C-600 - Normal View | Advanced View

View Larger Image

Part Number	Description	price
C-330-6	Tube Nut For 3/8" OD tubing Standard heavy duty compression tube nut. Ships in 1 to 3 business days.	$2.08
C-560-6V	Pump head adapter Adapter sub assembly with o-ring Adapter material = PVDF, O-ring material = Viton Ships in 1 to 3 business days	$18.15
C-560-6E	Pump head adapter Adapter sub assembly with o-ring Adapter material = PVDF, O-ring material = EP Ships in 1 to 3 business days	$18.15
K-568A-4	Bullet Valve, 4 kit Contains 4 double ball bullet valves (2 are reqd. per pump) Matls; Housing = PVDF, O-ring = Aflas, Ball = Ceramic Ships in 1 to 3 business days.	$58.36
C-406T	Diaphragm Material = Teflon coated EP Ships in 1 to 3 business days	$28.4
C-304	Yoke and Bearing sub-assembly For C-600 Chem-Feed Usually ships in 1 to 3 business days	$26.41
C-325	Cam sub-assmbly For C-600. Does not include yoke and bearing. Usually ships in 1 to 3 business days	$22.86
C-535	Pump head Molded heavy duty pump head Material = Polypropylene Ships in 1 to 3 business days	$27.96
C-504HD	Screw Pump head screw (10-32 x 1.25 pan) 1 screw (4 are required for pump head installation) Material = SS Ships in 1 to 3 business days	$0.67
C-535FC	Pump head cover Chem-Feed pump head cover Ships in 1 to 3 business days	$14.37
90011-155	Screw Cam cover screw (6-32 x .31 pan) To be used on the acrylic cam cover (1 is required) Material = SS Ships in 1 to 3 business days	$0.78
90002-201	Cam cover For C-600 cam cover Material = Clear Acrylic Ships in 1 to 3 business days	$6.64
C-301	Motor Mount For C-600 Chem-Feed Usually ships in 1 to 3 business days	$35.77
C-618P-14	Gearbox, 14 RPM For C-600 Chem-Feed For model # C-614P Usually ships in 1 to 3 business days	$126.86
C-618P-30	Gearbox, 30 RPM For C-600 Chem-Feed For model # C-630P Usually ships in 1 to 3 business days	$113.22
C-618P-45	Gearbox, 45 RPM For C-600 Chem-Feed For model # C-645P Usually ships in 1 to 3 business days	$122.86
C-618P-60	Gearbox, 60 RPM For C-600 Chem-Feed For model # C-660P Usually ships in 1 to 3 business days	$122.86
C-618P-125	Gearbox, 125 RPM For C-600 Chem-Feed For model # C-6125P Usually ships in 1 to 3 business days	$125.12
C-618P-250	Gearbox, 250 RPM For C-600 Chem-Feed For model # C-6250P Usually ships in 1 to 3 business days	$126.86
C-612PB	Bearing Bracket with bearing Quantity of two are required for the motor Usually ships in 1 to 3 business days	$24.45
C-625	Screw Used to attach Bearing Bracket and Rotor to Stator Assembly 8-32 x 2.5 Phil Rnd SS Usually ships in 1 to 3 business days	$0.9
C-612F	Fan Attach fan to Rotor Usually ships in 1 to 3 business days	$2.26
C-615P-1	Stator Assembly 115V / 60hz Wiring = Blue and Black Usually ships in 1 to 3 business days	$66.22
C-615P-2	Stator Assembly 230V / 60hz Wiring = Red and Black Usually ships in 1 to 3 business days	$80.61
C-615P-3	Stator Assembly 220V / 50hz Wiring = Brown and Blue Usually ships in 1 to 3 business days	$75.51
C-616PN	Rotor with spacers Rotor M-30 with shaft and spacers Usually ships in 1 to 3 business days	$38.83

Chem-Feed

Accessories

Part Number	Description	price
C-340A	Foot Valve and strainer, For 3/8" OD tubing, O-ring material = Viton / Aflas Body material = PVDF (Kynar) Usually ships in 1 to 3 business days	$23.41
C-346	Ceramic Weight Weight is used to keep a foot valve or a strainer at bottom of solution tank. Material = Ceramic MgSiO12 Usually ships in 1 to 3 business days	$4.61
C-335-6-25	Discharge tubing, 3/8" OD, 25 ft length, Material = Polyethylene Usually ships in 1 to 3 business days	$20.81
C-334-6-10	Suction tubing, 3/8" OD, 10 ft length, Material = Vinyl (Tygon) Usually ships in 1 to 3 business days	$9.63
FI-100-6V	Flow Indicator For 3/8" OD tubing Glass bobbin (standard) More Info. Install on the pump suction tubing. The glass float rises and falls as solution is pumped. Excellent diagnostic tool.	$29.31
FI-100S-6V	Flow Indicator For 3/8" OD tubing Stainless Steel bobbin More Info. Install on the pump suction tubing. The SS float rises and falls as solution is pumped. Excellent diagnostic tool.	$29.31
A-014N-6A	Injection Fitting, Threaded with 1/4" and 1/2" male NPT For 3/8" OD tubing. 1/2 lb. spring Material = Polypropylene Usually ships in 1 to 3 business days	$31.03
C-395N-6A	Injection Fitting, Threaded with 1/4" and 1/2" male NPT For 3/8" OD tubing. 6 lb. spring Material = Polypropylene Usually ships in 1 to 3 business days	$31.03
